PCB Inspection Vision System
Customer
Manufacturers of Consumer ElectronicsLocation
PuneApplication
Vision Inspection of PCBsTime/ Duration
May 2017, 6 weeks
Challenge
- Detection of small components on large PCBs
- PCB in motion during inspection
- Presence / Absence of small components to be detected
- Orientation of small components to be checked as against the master
- PCB movement of 20 PCBS / min
- Addition of new components and new PCBs in future
Solution
- High speed Camera optics and suitable illumination
- Image capture during motion and high speed software for detection
- Interfacing with conveyor PLC control system for line stoppage in case of any defect detection
- Configurable system for addition of any new component and build new PCB configuration
- No limit on number of components to be checked
- Reporting based on date and component types
